1-3oz Copper Impedance Control Multilayer PCB With Blue Mask Gold Plating

1-3oz Copper Impedance Control Multilayer PCB With Blue Mask Gold Plating

1-3oz Copper Impedance Control Multilayer PCB With Blue Mask Gold Plating

Brand Name:	hengsheng
Model Number:	HS6025
MOQ:	1 pz
Price:	USD 0.1-5/pcs
Delivery Time:	7-10 giorni
Payment Terms:	T/T, Western Union, PayPal

Detail Information

Descrizione del prodotto

Detail Information

Luogo di origine:

Cina

Certificazione:

UL, ROHS,SGS,ISO9001

Finito:

Placcatura in oro

Spessore del pannello:

0,2-3,2 mm

Spessore del rame:

1-3oz

Controllo dell'impedenza:

SÌ

Conteggio degli strati:

2-20

Materiale:

FR-4, FR-1, CEM-1, CEM-3

minimo Dimensione del foro:

0,2 mm

Min. Spaziatura della linea:

0,075 mm

Min. Larghezza della linea:

0,075 mm

Modo di spedizione:

DHL, FedEx, UPS, TNT, EMS

Silkscreen Color:

Bianco, nero, giallo

Colore maschera di saldatura:

Verde, blu, bianco, nero, rosso

Finitura superficiale:

HASL, ENIG, OSP, oro di immersione

Imballaggi particolari:

25 kg/cartone, imballaggio sottovuoto

Capacità di alimentazione:

100000 pezzi al mese

Descrizione del prodotto

Process Capability And Checking Parameters(Hard Board) NO ITEM Technical Capabilities 1 Layers 1-38L 2 Max.Board Size 1200*610mm 48"*24" 3 Finished Board Thickness 0.2mm--10.0mm 0.008"--0.4" 4 Finished Copper Thickness 17um-420um 0.5OZ--12OZ 5 Min.Trace Width/Space 0.075mm/0.065mm 0.003"/0.0026" 6 Min.Hole Size 0.15mm 0.006" 7 Hole Dim. Tolerance(PTH) ±0.05mm ±0.002" 8 Hole Dim.Tolerance(NPTH) ±0.05mm ±0.002" 9 Drill Location Tolerance ±0.05mm ±0.002&

Tags:

multilayer pcb

pcb multilayer

print circuit board
